Alexander Graham Bell's Telephone, 1876
| Partager |
|---|
 Pinterest |
 Twitter |
 Facebook |
 Copier le lien |
 Email |
|
Ajouter à une autre Lightbox |
|
Ajouter à une autre Lightbox |
Avez-vous déjà un compte? S'identifier
Vous n'avez pas de compte ? S'inscrire
Acheter cette image
Titre:
Alexander Graham Bell's Telephone, 1876
Légende:
Voir la traduction automatique
Replica of Bell's 1876 telephone transmitter (microphone) consisted of a double electromagnet, in front of which a membrane, stretched on a ring, carried an oblong piece of soft iron cemented to its middle. A funnel-shaped mouthpiece directed the voice sounds upon the membrane, and as it vibrated, the soft iron armature induced corresponding currents in the coils of the electromagnet. These currents, after traversing the wire, passed through the receiver which consisted of an electromagnet in a tubular metal can having one end partially closed by a thin circular disc of soft iron. When the undulatory current passed through the coil of this electromagnet, the disc vibrated, thereby creating sound waves in the air.
Crédit:
Album / Science Source / New York Public Library
Autorisations:
Modèle: Non - Propriété: Non
Questions sur les droits?
Questions sur les droits?
Taille de l'image:
3600 x 3319 px | 34.2 MB
Taille d'impression:
30.5 x 28.1 cm | 12.0 x 11.1 in (300 dpi)
